WATER SUCTION & DISCHARGE HEAVY DUTY HOSE

IS:3549 /1983 Type 2

Application: For dewatering and delivery

purposes during reflooding, handling for

waste water, sewerage and mud at

maximum working pressure of 0.7,1.0

and 1.5 MPa.

TYPE: Hose having smooth bore.

LINING: Natural/Synthetic/blend rubber

compound lining for the water and

abrasion resistance.

REINFORCEMENT: Reinforcement for the rubber

bias at approx. 45" angle combination

impregnated woven textile applied on

with galvanized steel wire.

COVER: Corrugated cloth marked finish outer cover made from natural rubber compound

resistance to water, sunlight, UV rays, ozone, abrasion etc.

PRESSURE: W.P. of 0.7MPa & min. B.P. of 2.1 MPa., W.P. of 1.0 MPa. & min. B.P. of 3.0 MPa., W.P. of 1.5 MPa & min. B.P. of 4.5 MPa.

W.P. : Working Pressure, P.P. : Proof Pressure, B.P. : Burst Pressure, 1MPa : 10.2Kgf/Cm2 1Kgf/Cm2:100KN/m2
